A perennial best seller, versatile hybrid with 24 gears, suspension fork with lockout and powerful hydraulic disc brakes. Shimano chainset and hubs for greater longevity.
The Crossway is the perfect blend of comfort, enjoyment and all-around practicality, suitable for leisure rides or commuting.
All disc brake models use the same lightweight aluminium frame with a steep, sloping top tube providing plenty of standover height.
For ultimate adaptability, the Crossway range can be equipped with mudguards, racks and kickstands.
Frame |
TFS II - 6061 double butted technoformed aluminium tubing with internal cable routing. Tapered head tube, inboard disc mounts, BSA BB standard, 135 x 9mm QR axle standard. Mounts for rack, mudguards and kickstand. Max. tyre size 700 x 50c |
Fork |
Suntour NEX HLO; Coil; 63mm travel; Lockout. Max. tyre size: 700 x 50c |
Gears | 24 |
Shifters |
Micro Shift TS39 |
Front Derailleur | Shimano FD-TY710 |
Rear Derailleur | Shimano RD-M359 |
Bottom Bracket | FSA TH-7420ST-W, Cartridge Bearing |
Chain | Sunrace M84 |
Chainset | Shimano TY301; 48-38-28 tooth chainset. Crank length: 170mm (S), 175mm (M,L) |
Cassette | Sunrace CSM558AU; 11-32 teeth; 8 speed |
Brake Lever | Shimano ST-EF505 |
Front Brake | Power DS-100HT; 2 piston hydraulic disc brake caliper with Shimano RT10; 160 mm rotor |
Rear Brake | Power DS-100HT hydraulic disc brake caliper with Shimano RT10; 160mm rotor |
Grip |
Merida EC |
Handlebar | Merida CC; aluminium; 660mm wide; 25mm rise |
Stem | Merida TK; aluminium; 25.4mm diameter; adjustable - Stem length: 100mm (all sizes) |
Headset | Merida M2340 |
Pedal | VP Components, VPE-891 |
Saddle | Merida Cross Sport |
Seatpost | Merida TK; 30.9mm diameter; 13mm setback; 40mm seatpost suspension travel |
Wheel Size | 700C |
Rims | Merida CC; 17mm inner rim width; Aluminium |
Spokes | Black Steel |
Front Hub | Shimano TX505; 100x9mm wide; 32 spoke holes; Center lock |
Rear Hub | Shimano TX505; 135x9mm wide; 32 spokes; Center lock |
Front Tyre | Merida K1171; 700x40C; wire bead |
Rear Tyre | Merida K1171; 700x40C; wire bead |
