THE TRAIL IS CALLING AND HERE’S YOUR ANSWER. THIS BALANCED SMOOTH-RIDING E-BIKE GIVES YOU A SMOOTH BOOST OF POWER AND TOTAL CONTROL SO YOU CAN HAVE MORE FUN AND EXPAND YOUR OFF-ROAD RIDING CAPABILITIES.
Smooth power delivery
The SyncDrive Core motor technology delivers smooth, instantaneous power to conquer all kinds of terrain and have more fun.
Balanced, confident handling
Lightweight aluminium frame with trail-friendly geometry, 100mm of front suspension travel, and fast rolling 27.5-inch or stable 29-inch wheels, with tubeless tyre compatibility puts you in control on off-road terrain.
Long-lasting battery
Side Release EnergyPak with 500Wh of capacity is easy to charge with our 4A smart charger.
How far can I expect to ride on a single battery charge?
The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tyre pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.
The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.
|
Motor
|
SyncDrive Sport, 70Nm, Powered by Yamaha
|
|
Controller
|
RideControl One
|
|
Battery
|
EnergyPak 500Wh
|
|
Charger
|
EnergyPak 4A fast charger
|
|
Sizes
|
S, M, L, XL
|
|
Colours
|
Matt Graphite
|
|
Frame
|
ALUXX aluminum, Overdrive 1½ - 1⅛ head tube, integrated KS18 kickstand mount
|
|
Fork
|
SR Suntour XCM ATB Coil 100mm travel, Tapered 1½ - 1⅛ steerer
|
|
Handlebar
|
Giant Connect TR Riser 31.8x690~750mm
|
|
Grips
|
Giant Sole-O Grip
|
|
Stem
|
Giant Contact
|
|
Seatpost
|
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
|
|
Saddle
|
Giant Sport
|
|
Pedals
|
Aluminum Platform
|
|
Shifters
|
Shimano Altus 1x9 speed
|
|
Rear Derailleur
|
Shimano Alivio
|
|
Brakes
|
Tektro HD-M275, hydraulic disc, 160/180mm
|
|
Brake Levers
|
Tektro HD-M275
|
|
Cassette
|
Shimano CS-HG200, 11-36T, 9-speed
|
|
Chain
|
KMC e.9 Sport, e-bike optimized
|
|
Crankset
|
FSA Comet E-Bike crank arm set FSA MegaTooth Direct-mount 1X steel 36T
|
|
Rims
|
Giant GX03V
|
|
Hubs
|
Giant eTracker Sport, QR
|
|
Spokes
|
Stainless steel
|
|
Tyres
|
Kenda Booster 29x2.2, wire bead
|
|
Weight
|
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
|
